FR1000

Unparalleled Computing Power

Powered by Octa-core 1.6 GHz high-performance CPU, FR1000 is equipped with strong processing power to simultaneously manage multiple processes

  • octacore Octa-core 1.6 GHz
  • android Android 10.0

Fast RFID Tags Reading in Batches

The industry-leading integrated Impinj E710 chip and the Self-Jammer Cancellation (SJC) technology enable the FR1000 to equip with higher read rate. It can capture max of 1000+ RFID tags/second.

Enhanced Security

The FR1000 enables you to manually change IPv6 addresses and proactively monitor the network, improving security and protecting your privacy.

Flexible Deployment Without Additional Power Socket

The FR1000 supports PoE+ (802.3at 25.5W) power supply mode. It can be flexibly deployed in the desired position without additional power sockets,greatly reducing the time and deployment costs.

Rugged and Durable Design for Tough Environments

The FR1000 made of cast aluminum housing has superior thermal management which ensures stable performance and output, delivering the durability you need to ensure uptime — even in damp, dusty work areas, extreme heat or subzero temperatures.

Great Compatibility & Improved Accuracy

- Eight external SMA antenna ports improve the accuracy and increase the reading range.

- The independent anti-interference technology of WiFi/Bluetooth antenna and GPS antenna significantly improves the communication efficiency.

Efficient Management Tools

Equipped with integrated HDMI, RJ45, RS232, GPIO and other interfaces, FR1000 can centrally manage various tools in a variety of RFID applications

HDMI

RJ45

RS232

GPIO

Adaptable to Various Industry Scenarios

FR1000 applies to various industry scenarios, such as retail, jewelry, banking, archives, library, and medical care.

1
2
3
4

FR1000

Quad-core processor
CPU

Octa-core 64-bit, 1.6 GHz

Android
OS

Android 10.0

Memory
Memory

RAM: 4 GB
ROM: 64 GB

Video

Video

1,920x1,200P HD format
video output

Positioning
Positioning

GPS + GLONASS or GPS + BeiDou

Dimensions
Dimensions

180 mm x 128 mm x 28 mm

Interface
Interface

DC JACK, USB interface * 3, HDMI interface, RJ45 (PoE supply mode), RS232, GPIO interface,
SMA antenna interface ANT1~ANT8

Antenna
Antenna

GPS antenna, WiFi/Bluetooth antenna

Communation
Communication

2.4G/5G dual-band WIFI
Bluetooth 5.0

Environmental
Environmental

Operating temperature: -30℃ to +70℃
Storage temperature: -40℃ to +85℃
Humidity: 5%-95% RH (non-condensing)

* Please note that this introduction will be adjusted with the product updates, and the information is subject to change without prior notice.
